WM-5325 G01
充電式腰掛式麥克風(不含MIC UNIT)
WM-5325 G01
WM-5325 無線發射器專為與 UHF 系統搭配使用而製造。它用於語音增強應用。由於採用 PLL合成器系統，可提供 64 種不同的工作頻率。高輸出功率確保無線電訊號傳輸穩定。
- 超高頻腰包式發射機，覆蓋範圍廣
- 結構緊湊、超輕，可輕鬆長時間攜帶
- 配有皮帶夾和長度可調的頸帶
- 覆蓋範圍廣，電池耐用性高
- 專為語音應用而開發
頻率範圍
606 - 636 MHz, UHF
頻道選擇
64 channels (the number of channels may differ from country to country)
RF載波功率
Less than 50 mW (Factory preset 10 mW ERP)
Tone Frequency
32.768 kHz
最大輸入電平
-14 dB to -29 dB (Audio level control: Min. to Max.)
Maximum Deviation
±40 kHz
音聲頻率響應
100 Hz – 15 kHz
電池
WB-2000 rechargeable battery (option) or AA alkaline dry cell battery
電池使用壽命
Approx. 13 h (when the WB-2000 rechargeable battery is used)
Approx. 10 h (when the alkaline battery is used)
Approx. 10 h (when the alkaline battery is used)
指示燈
Power/Battery lamps
天線
Built-in type
連接
ø3.5 mm (ø0.14") mini plug
工作溫度
–10°C to +50°C (14°F to 122°F) (except battery)
工作濕度
30 % to 85 %RH
外觀
Resin, coating
尺寸
62 (W) x 102.5 (H) x 23 (D) mm (2.44" x 4.04" x 0.91")
重量
90 g (0.2 lb) (with battery)
附屬品
Screw driver x 1, Storage case x 1, Neck strap x 1
選配品
Battery charger: BC-5000-2, BC-5000-6, BC-5000-12
Ni-MH battery: WB-2000-2 (containing 2 pieces)
Omnidirectional lavalier microphone: YP-M5310
Headset microphone: WH-4000A, WH-4000H
Ni-MH battery: WB-2000-2 (containing 2 pieces)
Omnidirectional lavalier microphone: YP-M5310
Headset microphone: WH-4000A, WH-4000H
請下載資料以獲取完整規格。
UHF Bodypack Transmitter with integrated antenna. Flat casing, switch and power indicator at the top clearly visible and accessible installed. Adjustable microphone sensitivity. Frequency selection out of 64 channels, up to 16 inter modulation free frequencies for simultaneous interference-free transmission of several wireless microphones. Battery condition monitoring with timely reference to necessary battery led on the transmitter and transfer the receiver battery status. Identification signal system to avoid interference when transmitter is switched off in difficult environments. Extremely stable and precise frequency transmitter through quartz stabilized PLL synthesizer. Communication port for PC to change the carrier frequencies adjustable on the transmitter. More than 10 hours of operation with a 1, 5V alkaline AA battery or 13 hours with the optional rechargeable battery WB-2000. Rechargeable in optional charger without battery removal. Storage case, neck strap and screwdriver to set the frequency in the scope of delivery.
- Transmission frequency range: 576 MHz - 937.5 MHz (UHF)
- Channel selectable: < 64
- Simultaneous channels: < 16
- Transmitter power: < 50 mW
- Characteristic frequency: 32.768 kHz
- Battery: 1 x 1, 5V AA battery
- Dimensions (W x H x D): 62 x 102.5 x 23 mm (2.44" x 4.04" x 0.91")
- Weight: 90 g (0.2 lbs) (incl. battery)
- Color: black
- Manufacturer: TOA
- Model: WM-5325
