VP-2122
功率放大器
VP-2122
VP-2122 功率放大器採用 120 W x 2 通道配置，每個通道使用 VP-200VX 功率放大器模組。
- 電源配置：120 W x 2 頻道
- 可用作緊急切換的備用功放
- 擴大機使用 1 個 VP-200VX 擴大機輸入模組每個通道
- 可程式擴大機功能可延長緊急情況下電池供電的操作時間
電源
28 V DC (operating range: 20 – 40 V DC)
M4 screw terminal, distance between barriers: 12 mm
M4 screw terminal, distance between barriers: 12 mm
消耗電流
0.04 A (standby mode), 0.40 A (no audio input),
4.8 A (1/8 rated output, EN60065), 17 A (rated output) channel total
4.8 A (1/8 rated output, EN60065), 17 A (rated output) channel total
額定輸出
120 W x 2 (at min. resistive and max. capacitive load)
Output Power (at AC Mains: 195.5 V)
90 W x 2 (at min. resistive and max. capacitive load)
Output Voltage
100 V (70 V, 50 V: selectable by internal wiring change)
Minimum Impedance Load
83 Ω (at 100 V), 41 Ω (at 70 V), 21 Ω (at 50 V)
Maximum Capacitive Load
0.25 μF (at 100 V), 0.5 μF (at 70 V), 1 μF (at 50 V)
Number of Channels
2
輸入
Specified by input module VP-200VX
Number of Module Slots
2, usable module: VP-200VX
輸出
Power amplifier output (speaker line):M3.5 screw terminal, distance between barriers: 8.8 mm
頻率響應
40 Hz – 16 kHz, ±3 dB (at 1/3 rated output)
失真率
1% or less (at rated output, 1 kHz)
S/N比
80 dB or more
指示燈
Channel power indicator: 2 channels, dual color LED
Overheat indicator: Yellow LED
Overheat indicator: Yellow LED
工作溫度
0 °C to 40 °C
外觀
Panel: Surface-treated steel plate, black (30% gloss), paint
尺寸
482 (W) x 88.4 (H) x 345 (D) mm
重量
9.1 kg
附屬品
Rack mounting screw x 4, Fiber washer x 4
請下載資料以獲取完整規格。
功能/操作擴充相關配件
2-channel power amplifier with 2 x 120W power on
50V-,, 70V-and 100V-Linien, proof against short circuit and open circuit-sure, overheating protection. Cross flow air flow by means of temperature-controlled fan cooling. Connecting the loudspeaker outputs on screw terminal. Slot for different input modules.
Controllable by the system standby mode with very low power consumption and fast reclosing (< 0.5 seconds).
Controllable by the system standby mode with very low power consumption and fast reclosing (< 0.5 seconds).
