NX-100S
網路音聲傳輸器
NX-100S
NX-100S網路音訊轉接器可透過IP網路（例如LAN或Internet）即時傳輸高品質的音訊訊號和控制輸入資料等控制資料。
當將音訊訊號傳輸到遠端位置時，它特別有用，因為使用網路可以使運行成本低於使用專用線路。透過使用選購的機架安裝支架，可以將其安裝在 EIA 標準機架中
- 音訊網路轉接器，用於透過 LAN 傳輸音訊和控制訊號
- 同時傳輸至多達 64 個 NX-100S
- 允許 VX-2000 的分散式安裝系統
balanced (MIC/LINE changeable, volume adjustable with volume control),
2 kΩ, removable terminal block (3 pins),
phantom power supply (24 V, can be set with the switch)
removable terminal block (3 pins)
short-circuit current: 10 mA, removable terminal block (9 pins)
control current: 50 mA max., removable terminal block (9 pins)
Multicast (Up to 64 simultaneous transmissions)
MB-15B-J (for rack mounting two NX-100S units)
AC adapter: AD-246
請下載資料以獲取完整規格。
The network audio codec shall be IP-addressable and convert analog audio (mic or line level) to standard IP packets for transport over an IP-based network including local area, wide area and the Internet. The device shall be capable of simultaneous transport of audio and contact closures. The device shall support three audio quality modes and have variable sample rate and audio bandwidth with a minimum latency/delay of 20 ms. Multiple error correction modes shall be available to address potential packet loss in high network traffic environments.
The network interface shall be 10BASE-T/100BASE-TX, Auto-Negotiation and utilize the network protocols TCP/IP, UDP, HTTP and RTP. The audio input shall be balanced, transformer-isolated, MIC/LINE switchable (-58 dBV to 0 dBV, 2k ohms) with adjustable volume control and plug-in screw connector. The audio output shall be balanced, transformer-isolated, (0 dBV, 600 ohms), with plug-in screw connector. Specifications shall include frequency response of 50 to 14k Hz and distortion of under 0.3% (1k Hz, sampling frequency 32k Hz).
The unit shall be capable of Unicast transmission to up to 4 simultaneous units/locations over LAN/WAN/Internet, and Multicast transmission to up to 64 simultaneous units/locations over LAN/WAN. The device shall include Java-based software for configuration, operation and management with password protected access. The device shall include a built-in web server for control and monitoring from any network-based PC with password protected access.
The control inputs shall include 8 channels, no-voltage make contact input, open voltage: 12 VDC,short-circuit current: 10mA with plug-in screw connector. The control inputs shall be individually programmable to initiate and terminate stored transmissions without the need for dedicated PC-based or other control equipment. Each unit shall have twenty programmable distribution presets. The control outputs shall include 8 channels, open collector output, withstand voltage: 30 VDC, control current: 50 mA max. with plug-in screw connector. Adjustable contact off delay time shall be available.
The front panel shall include Link/Active, Full-Duplex/Collision, Signal, Peak, Status, Error, Run LED indicators plus recessed Reset button. Firmware shall be FLASH-type and upgradeable from any network PC. Power requirements shall be AC adapter (optional) with 24 VDC output with current consumption of 200 mA. The finish shall be black steel plate, 30% gloss. Dimensions (W x H x D) shall be 8.27” x 1.81” x 7.4” (210 x 46 x 188 mm) and weight shall be 2.65 lbs. (1.2 kg).
The network audio adapter shall be TOA model NX-100S
The AC power supply shall be TOA model AD-246.
The rack-mount kits shall be TOA model MB-15B-BK (1 NX-100S).
The rack-mount kits shall be TOA model MB-15B-J (2 NX-100S).
