M-633D

數位混音器

M-633D

M-633D為數位式前級混音器。可針對環境自動調校最合適的音場。

一鍵式操作
自動諧振控制(ARC)，具有室內模式頻率檢測和反向響應曲線補償
自動防夾(ACG)
自動回饋抑制器(FBS)
自動靜音功能
清晰、清晰的聲音
1 個單位高度

規格 A&E規格下載

* 0 dB = 1 V

電源

100 - 120 V AC, 60 Hz

消耗功率

14 W

頻率響應

20 Hz - 20 kHz

取樣頻率

48 kHz

Dynamic Range

90 dB or more (IHF–A weighted)

失真率

0.03% or less, 1 kHz, –10 dB* input, 0 dB* output (20 Hz – 20 kHz, BPF)

輸入

6 monaural input channels (MONO IN 1 – 6), selectable independently from 3 types of inputs below for each channel
LINE: –10 dB*, 2.4 kΩ, electronically balancedl
MIC: –46 dB*, 2.4 kΩ, electronically balancedl
PHANTOM: –46 dB*, 2.4 kΩ, supplies phantom power of +24 V DC, 10 mA,l
electronically balanced Removable terminal block (3P), phone jackl
3 stereo inputs (L, R) (STEREO IN 1 – 3) : –10 dB*/10 kΩ, RCA jack (STEREO IN 1 – 3), Stereo mini jack (ST IN 1)l

輸出

2 monaural output channels (MONO OUT 1, 2): 0 dB* (applicable load: over 1 kΩ), electronically balanced, removable terminal block (3P)
1 stereo output (L, R) channel (ST OUT L, R): 0 dB* (applicable load: over 1 kΩ), electronically balanced, removable terminal block (3P)
1 stereo reccording output (L, R) channel (REC OUT L, R): –10 dB* (applicable load: over 1 kΩ), RCA jack

Bus Line

Monaural channel x 2, Stereo channel x 1

A/D轉換器

24 bits

D/A Converter

24 bits

Digital Signal Processing

Automatic Resonance Control (ARC)

3 output channels (each monaural output channel, stereo output L, R),
independent settings for each channel, automatic creation of EQ curves (for sound field compensation)
ARC measurement start switch x 1, Function ON/OFF check indicator x 1

Feedback Suppressor (FBS)

6 channels (each monaural input channel), independent settings for each channel
Function ON/OFF switch x 6, Function ON/OFF check indicator x 6

Automatic Clip-guard (ACG)

6 channels (each monaural input channel), independent settings for each channel

Automatic Mute

Function ON/OFF switch x 1

Input Level Indicator

2-color LED indicator: Green (for appropriate level)/red (for peak level)

Output Level Indicator

2-color LED indicator: Green (for appropriate level)/red (for peak level)

工作溫度

0 °C to 40 °C (32 °F to 104 °F)

工作濕度

Under 90% RH (no condensation)

外觀

Panel: Aluminum, black, hair-line
Case: Precoated steel sheet, black, 30% gloss

尺寸

420 (W) x 44 (H) x 341.3 (D) mm (16.54” x 1.73” x 13.44”)

重量

4.0 kg (8.82 lb)

附屬品

Power cord (2 m (6.56 ft) ) x 1, Removable terminal plug (3 pins) x 10, Rubber foot x 3, Rack mounting bracket x 2, Machine screw (M3 x 8) x 6, Rack mounting screw (5 x 12) x 4

請下載資料以獲取完整規格。

Easy to use compact digital mixing system with feedback suppressors and auto-resonance control in a 19 "enclosure with one unit height."
6 balanced mic / line inputs for microphones or recording devices in mono via pluggable connectors and balanced TRS Jack, sensitivity individually selectable phantom power for microphones can be activated individually.
Three stereo inputs via cinch Sockets (RCA Sockets) for recording devices, individually switchable to the mixing of the left and right channel to the Mono summation.
All inputs switching and mixable can be protected on a stereo master and 2 mono sum, the edge by a cover against unauthorized access.
Optional auto-hide the three stereo inputs with signal on the mono inputs by voice activation (VOX).
Two mono outputs and a stereo output via pluggable connectors with own volume plates as well as a stereo recording connection via cinch Sockets (RCA Sockets).
Integrated automatic feedback suppressors (FBS) to increase the possible output volume for all mono channels can be activated individually. By suppressing the feedback frequencies only to the necessary level hardly any influence on the sound quality.
Anti-resonance control for improving speech intelligibility by reducing the resonance excitation in the room separately for the Mono outputs and stereo out just a measurable.
