EV-700
數位語音合成錄/放音器
EV-700
EV-700 是一款能夠錄音/播放的數位廣播機。它非常適合商業和公共設施中的期刊、提醒注意和指南廣播用途。使用設定軟體可以輕鬆進行音源重寫、設定和控制。預設聲音來源（如鐘聲和威斯敏斯特鐘聲）儲存在隨附的記憶卡上。 EV-700 可透過選購的機架安裝支架（1U 尺寸）安裝在 EIA 標準配備機架中。
- 非常適合預先錄製的廣告和緊急訊息
- 遠端變更節目、錄製、播放、刪除和停止
- 緊急訊息優先級
- 各種預先錄製的音訊文件，包括預告、鈴聲、鐘聲、旋律
- 免費訊息配置，包含32,768 個短語中的多達256 個程式
- 可提供預播鑼和鈴聲
- 高品質錄音時間長達4 小時
- 最多可容納2 張記憶卡（含1 張）
- 16 個控制輸入/8 個輸出
電源
Supplied from an external 24 V DC/400 mA power supply, Removable terminal block (2 pins) or from an optional AD-246 AC adapter
消耗功率
10 W
Wave Format
44.1 kHz/32 kHz sampling rate, 16 bit PCM method, WAV file (monaural)
Sound Source Rewriting Method
LAN data transfer/Analog recording/Direct write to memory card using the EV-700 setting software
頻率響應
20 Hz − 20 kHz ±3 dB (1 kHz)
50 Hz − 14 kHz ±3 dB (IT-450 mounted, 1 kHz)
50 Hz − 14 kHz ±3 dB (IT-450 mounted, 1 kHz)
失真率
0.3 % or less (1 kHz, rated output)
Storage Media
Compatible with CompactFlash™ specification Memory card
音聲輸入
MIC: −55 dB* 1 (microphone input volume control in maximum position), 600 Ω, unbalanced, φ6.3 phone jack (2P)
LINE (rear): −20 dB*1 (line input volume control in maximum position),10 kΩ, unbalanced, Removable terminal block (12 pins)
LINE (front): −29 dB*1 (line input volume control in maximum position), 10 kΩ, unbalanced, RCA pin jack
LINE (rear): −20 dB*1 (line input volume control in maximum position),10 kΩ, unbalanced, Removable terminal block (12 pins)
LINE (front): −29 dB*1 (line input volume control in maximum position), 10 kΩ, unbalanced, RCA pin jack
音聲輸出
LINE 1, 2: 0 dB*1, 600 Ω, unbalanced, Removable terminal block (12 pins)
Headphones: 0 dB*1, 100 Ω, monaural, φ3.5 mini jack (3P)
Headphones: 0 dB*1, 100 Ω, monaural, φ3.5 mini jack (3P)
控制輸入
Activations 1 - 16, playback, stop, recording, erasure/clear, emergency playback, emergency recording, emergency stop
No-voltage make contact input, pulse make length: 50 ms or more,
open voltage: 30 V DC, short-circuit current: 10 mA, Removable terminal block (12 pins, 16 pins)
No-voltage make contact input, pulse make length: 50 ms or more,
open voltage: 30 V DC, short-circuit current: 10 mA, Removable terminal block (12 pins, 16 pins)
控制輸出
Shorting outputs 1 − 8 (busy), Error: contact capacity: 30 V DC, 0.5 A, Removable terminal block (8 pins)
Number of Mountable Memory Cards
2 (1 Memory card containing preset sound sources is supplied.)
Backup operation available when 2 cards are mounted.
Backup operation available when 2 cards are mounted.
Number of Recordable Phrases
32768
Number of Playback Program
Direct mode: 16 programs
Binary mode: 256 programs
1 emergency message takes precedence over the above programs and is played back.
R.E.M. (Recording Endless Message) playback*2 can be performed.
Binary mode: 256 programs
1 emergency message takes precedence over the above programs and is played back.
R.E.M. (Recording Endless Message) playback*2 can be performed.
Maximum Recording Time
About 3 hours (at 44.1 kHz sampling rate) or about 4 hours (at 32 kHz sampling rate)
Audio Output Method
Single channel monaural
Network
Network I/F: 100 BASE-TX
Network protocol: TCP/IP, UDP, HTTP, FTP
Connector: RJ45 connector
Network protocol: TCP/IP, UDP, HTTP, FTP
Connector: RJ45 connector
Operating Display
7-segment LED, 5 digits
工作溫度
0 to 40 ºC (32 to 122 ºF)
工作濕度
90 %RH or less (no condensation
外觀
Panel: Aluminum, black, 30 % gloss, paint
Case: Pre-coated steel plate, black, 30 % gloss
Case: Pre-coated steel plate, black, 30 % gloss
尺寸
420 (W) x 44 (H) x 222 (D) mm (16.54" x 1.73" x 8.74")
重量
2.4 kg (5.29 lb)
附屬品
Memory card (1 GB, Containing prerecorded audio files) x 1, Rubber foot x 4, Removable terminal plug (2 pins) x 1, Removable terminal plug (8 pins) x 2, Removable terminal plug (16 pins) x 2, Removable terminal plug (12 pins) x 2, Front cover fixing screw x 2
選配品
AC adapter: AD-246, Rack mounting bracket: MB-15B
(*1) 0 dB = 1 V
(*2) An emergency broadcast function that repeatedly plays the sound source recorded on the spot with the highest priority in case of an emergency situation.
Line output can be converted to balanced type using an optional IT-450 transformer.
CompactFlash is a trademark of SanDisk Corporation.
(*2) An emergency broadcast function that repeatedly plays the sound source recorded on the spot with the highest priority in case of an emergency situation.
Line output can be converted to balanced type using an optional IT-450 transformer.
CompactFlash is a trademark of SanDisk Corporation.
請下載資料以獲取完整規格。
可選配件
The digital announcer shall be capable of recording and play back of audio files that are created via the attachment of a microphone or from pre-recorded WAV files.
These WAV files are directly stored to a supplied 1 GB memory card within the unit that can be accessed from the front panel. An additional memory slot shall be available for backup purposes. The WAV files can be distributed automatically, activated by an external device, in timed and repeated fashion, with a broadcast quality of 44.1kHz/32 kHz sampling rate, 16 bit PCM and a frequency response of 20 Hz – 20 kHz.
Creation and editing of various sound source files and programs, updating of settings and activation of announcements shall be by direct input or managed remotely via a network.
The digital announcer shall be able to store 32,768 WAV files (phrases) and 256 audio programs on its memory card that can be edited directly by inputting new phrases or combing pre-recorded phrases. Any combination of program files and WAV files can be achieved. A maximum of 3 hours at 44.1 kHz sampling rate, or 4 hours at 32kHz sampling rate can be achieved
Network shall be made possible using RJ45 connection via switching hub. Network I/F: 100BASE-TX Auto-Negotiation utilizing network protocol TCP/IP, UDP, HTTP, FTP.
The unit shall be able to prioritise pre-recorded emergency broadcast messages that will take precedence over any output signal that may be already being broadcast.
The unit shall have pre-recorded WAV samples that may be used.
Example:
a) Attention please. The fire alarm is indicating a fire. We're now investigating the cause. Please wait for further information.
b) There is a fire. Please evacuate as quickly as possible.
c) Attention please. A few minutes ago, we announced there maybe a fire. However, this was a false alarm. Once again, there is no fire.
The broadcasting zones and number or lengths of repeat broadcasts can be set in advance. The unit shall be able to broadcast R.E.M. (Recording Endless Message) enabling operators to create/initiate repeated play back of emergency announcements quickly and evacuate with other occupants before anticipated emergencies.
The digital announcer shall include intuitive GUI (Graphic User Interface) control software for PC operation and settings, which will allow networked location to create, edit, store and activate broadcast programs. The timing of new or edited programs and settings can be synchronized so that programs are broadcast simultaneously in every location on the network.
The software shall have two modes: Full-function mode for management or detailed settings by equipment administrator and Simple mode for basic operation.
Power requirements shall be 24 VDC (plug-in screw connector) or an optional AC adapter.
It shall use only one EIA component rack space and its dimensions shall be 420 (W) × 44 (H) × 222 (D) mm (16.54" × 1.73" × 8.74") Weight shall be 2.4 kg (5.29 lb.) and finished in black aluminium front panel with surface-treated steel plate case.
Optional extras: AC adapter: AD-246, Rack mount bracket: MB-15B manufactured by TOA Corporation
Manufacturer: TOA Corporation
Model: EV-700
